800mm bucket wheel dredger for mineral mining
product description
The chain bucket dredger is a mechanical dredger with a long history and wide application. Its core feature is that it
uses an infinitely circulating chain bucket wrapped around a bucket bridge (also called a guide frame) to continuously
excavate underwater soil or silt.
product parameters
|
Model
|
YSBCD80
|
YSBCD100
|
|
Capacity(m3/h)
|
80-100
|
120-150
|
|
Dredging depth(m)
|
1-10
|
1-15
|
|
Main engine power(kw)
|
45
|
75
|
|
Main reducer
|
ZQ750
|
ZQ1250
|
|
Bucket
|
800mm
|
1000mm
|
|
Chain
|
600*90*22mm
|
650*90*25mm
|
|
Big Arm Winch
|
15kw-6
|
22kw-6
|
Working principle:
The bucket bridge is lowered to the bottom of the water, and the lower guide wheel (or the end of the bucket bridge)
at its bottom contacts the excavation surface.
The power drives the upper guide wheel to rotate, driving the bucket chain to circulate along the bucket bridge track.
When the bucket runs to the bottom of the bucket bridge, it cuts into the bottom soil or silt and digs it up.
The bucket filled with materials runs upward along the chain and crosses the water body.
When the bucket runs to the top of the bucket bridge, the bucket flips or pours the materials into the discharge chute
through the unloading mechanism.The empty bucket runs down along the outside (or inside) of the bucket bridge and
returns to the bottom to start the next excavation cycle.
By retracting and releasing the anchor cable or operating the positioning pile, the whole ship moves slowly in steps so
that the bucket chain covers the new excavation surface.
Why Choose a Chain Bucket Dredger?
Chain bucket dredgers are the preferred choice for projects requiring reliability, durability,
and efficiency. Whether you're mining valuable resources, maintaining waterways, or
restoring ecosystems, these dredgers deliver consistent performance in even the most
challenging conditions.
