Jet-suction dredger creates intelligent and environmentally friendly dredging
Product description
The jet-suction dredger is a highly efficient and environmentally friendly equipment in modern dredging projects.
It adopts the innovative working principle of "high-pressure jet crushing + vacuum suction dredging",which perfectly
solves the efficiency bottleneck of traditional dredgers in soft bottom operations. This equipment is particularly
suitable for engineering projects with strict environmental protection requirements such as urban river management,
ecological dredging, and port maintenance.
product parameters
|
Model
|
Total power
|
Output per hour
|
Water flow rate
|
Pumping depth
|
Lift head
|
Transport
distance
|
|
YSJSD100
|
20-60kw
|
30-45m3/h
|
200-300m3/h
|
0-20m
|
20-40m
|
20-2000m
|
|
YSJSD150
|
45-100kw
|
50-90m3/h
|
350-600m3/h
|
0-25m
|
20-65m
|
20-2000m
|
|
YSJSD200
|
75-200kw
|
90-120m3/h
|
600-800m3/h
|
0-25m
|
20-65m
|
20-2000m
|
|
YSJSD250
|
90-300kw
|
140-195m3/h
|
c
|
0-30m
|
20-65m
|
20-2000m
|
|
YSJSD300
|
190-600kw
|
225-330m3/h
|
1500-2200m3/h
|
0-30m
|
20-65m
|
20-2000m
|
|
YSJSD350
|
290-800kw
|
330-390m3/h
|
2200-2600m3/h
|
0-30m
|
20-65m
|
20-2000m
|
|
YSJSD400
|
350-1000kw
|
420-480m3/h
|
2800-3200m3/h
|
0-30m
|
20-65m
|
20-2000m
|
|
YSJSD450
|
450-1200kw
|
480-570m3/h
|
3200-3800m3/h
|
0-30m
|
20-65m
|
20-2000m
|
|
YSJSD500
|
600-1500kw
|
540-630m3/h
|
3600-4200m3/h
|
0-30m
|
20-65m
|
20-2000m
|
Technical highlights
Intelligent control system
1. Equipped with dredging trajectory planning system, automatically optimize the operation path
2. Real-time monitoring of mud concentration, intelligent adjustment of jet pressure
3. Integrated 5G remote monitoring module, support real-time control of shore-based command center
Efficient power configuration
1. Optional hybrid power system (diesel engine + lithium battery pack), energy saving 30%
2. The main mud pump adopts variable frequency control, and the flow adjustment range is 200-3000m³/h
3. Unique multi-stage jet device, crushing efficiency increased by 40%
Environmental design
1. Low disturbance jet technology, suspended matter diffusion reduced by 60%
2. Optional mud and water separation system to achieve on-site solid-liquid separation
Why choose us?
1.Mature technology - 20+ years of experience in designing and manufacturing suction dredgers, with
products exported to 30+ countries.
2.Customized service - adjust the mud discharge capacity, hull size and power configuration according
to customer needs.
3.Full support - provide on-site commissioning, operation training and long-term maintenance services.
